Bright Digital Signage display with 24 inch vandal-proof screen shows promotional videos, informational messages, banners and entertaining video files in Full HD quality. DIPANEL-2350-BLK LCD advertising player is good for advertising in transport, near the elevators, as well as for digital signage systems in retail stores – at the counters, shelves with goods, and at the box office. It is recommended to use this screen as:
Display for Digital signage advertising in shops and waiting rooms
Information monitor in buses of small and large capacity
A video screen for trolleybuses and trams
TV for trains
Advertising monitor for elevators and hallways of office centers
Screen for POS materials
HoReCa advertising LCD player
The schedule screen performances
Digital electronic pointer or poster
This Digital Signage commercial monitor is a high definition screen with integrated advertising player in a vandal-proof metal case. This large-format digital signage video system, also known as DILUX or promotional digital signage screen, plays video clips of AVI and MKV H264, JPEG files in portrait or landscape orientation, as well as sound files MP3 and FLAC. Please note that, no matter where you use the monitor, it can show images in both horizontal and vertical format. A large digital screen with narrow frame in the style of the DILUX can be used as digital signage in the store or in transport, and mounted on standard VESA100 or VESA200-compatible bracket for wall mounting. Transport mounting is also available for installation of advertising display on the ceiling and on to the handrails of bus or trolley. Although the preferred mounting is on the partition behind the driver with steel bolts.
Management of digital signage information is possible via WIFI or 4G Internet access (optional). Standard playlist and the videos are updated by changing the USB flash disk or SD/MMC memory card.



Basic functions of LCD ad player

Auto start of displaying video at power-up, no need to turn on manually. Automatic on and off on a schedule. Support Full HD video, image files, MP3, lossless audio. Automatic playlist repeat around the clock all year round. Automatic restart in case of power failure. Scroll text with the color setting and size of letters and the substrate, the Update of information on the SD flash card c USB flash, view Statistics of mediaflow, Optional remote control via WIFI, 3G, 4G Internet. You can update your playlist, media, schedule. Watch full list of this model functions...


Main features of DIPANEL Digital Signage Display

Rugged vandal-proof metal housing with simple design. Can be installed on the wall, the ceiling, on the Desk or on a shelf of a store. Can be used as a monitor for bus, taxi, metro cars, and train stations. Equipped with transparent screen protection made of tempered glass or plastic. Flash card, and USB flash is lockable to protect against theft. Multilingual settings menu. Built-in speakers 2x2W or 2x4W, see the full list of features...


Options of DIPANEL display series

  • Option: Remote display management via LAN/Internet remote updating of media files and playlists
  • Option: Built-in Android or Linux PC
  • Option: Built-in Windows PC
  • Option: Touch screen (touchscreen)
  • Option: Motion sensor
  • Option: Hot and cold conditions version
  • Option: Ultrabright screen for visibility in sunlight
  • Option: I/O Interface RS232
  • Option: Built-in memory
  • Option: Internet WiFi
  • Option: Internet – 3G / 4G
  • See the full list of options...



Interfaces:

  • SD flash card
  • CF flash card
  • USB flash
  • Option: AV input(CVBS)
  • Option: HDMI video + audio
  • Option: DisplayPort
  • Option: VGA / RGB video
  • Option: Audio input or output
  • Option: Antenna (coaxial cable)
  • Option: Internet – Wire RJ45
  • Option: Internet WiFi
  • Option: Internet – 3G / 4G
  • See the full list of interfaces...

Specification DIPANEL-2350-BLK

General
Application Bus display, Transport advertising screen, Indoor Advertising monitor, LCD advertising player, Digital signage, Standalone LCD ad player, Advertising display
Housing material Metal
Color Black, White (other by request)
Power input 9-30V for transport, 100-300V for indoor
Power consumption 15W
Operating System AdPlayer / Windows / Linux / Android
OSD language English, Chinese, Japanese, Spanish, Deutsche, French, Portuguese, Italian, Russian ...
Speakers 2x4W
Internal memory No
Optional internal memory 2-32GB
Storage temperature -35...+45C (-15...113F)
Operation temperature -25...+45C (-13...113F)
Flash memory support SD, SDHC, MMC/MS, USB flash
Flash memory anti-theft Cardreader door with lock
Mount method Wall, Сeiling, Handrail, Stand, VESA75/100 Mounting
Accessories Mounting kit, Remote Control, Manual
May also need SD/SDHC/MMC/MS or USB flash
Screen
Screen size 23.5 inch
Aspect ratio 16:9
Available sizes 10, 12, 15, 17, 19, 22, 24, 32, 42, 55, 65 ,70 inch
Screen protection Tempered glass or Acrylic glass, 1-6 mm ( 3/64 - 1/4 inch)
Screen type LCD
Optional screen type LED, IPS
Resolution 1920x1080
View angle H/V 178/174
Brightness 300 cd/m2
Contrast ratio 900:1
Supported colours 16.7 million
Response time 3 ms
Media support
Video files AVI, MPG, VOB, MPEG-1, MPEG-2, MPEG-4, H264, Matroska MKV (FullHD)
Picture files JPG, GIF, BMP, PNG
Audio files MP3, WMA, OGG, WAV, AAC, FLAC
Size and Weight
Product size (mm) by request
Product weight (kg) by request
Carton size (mm) by request
Carton G.W. (kg) by request
Packing details by request
